Key features:

1. Printing speed: Min 50.8 mm/s, Max 101 mm/s
2. Print width: 48mm
3. Maximum roll diameter: 50mm
4. Support thermal paper/thermal adhesive paper
5. Applications: Shopping, Mart, Restaurant, Hospital, Coffee Shop, Ticketing
6. Printing features: Label print mode & Receipt print mode

Label print mode:
Printing method: Direct thermal
Resolution: 203 DPI
Print width: Max. 48mm
Max. print speed: Min. 50.8mm/s, Max. 101 mm/s

①Media:
Media type: Thermal paper roll/ Thermal adhesive paper
Media width: 20mm ~ 60mm
Media external diameter: 50mm
Paper out method: Tearing-off

②Performance Features:
Print head detection: Thermistor
Print head position detection: Micro Switch
Media detection: Photoelectric Sensors
Interface: USB + Bluetooth
Storage: Flash 576 kb

③Fonts/Graphics/Symbologies:
Character size: Font 0 to Font 8
1D bar code: CODE128、EAN128、ITF、CODE25、CODE39、CODE39C、CODE39S、 CODE93、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、 CODABAR、POSTNET、UPC-A、UPCA+2、UPCA+5、UPCE、UPCE+2、 UPCE+5、MSI、MSIC、PLESSEY、ITF14、EAN14

2D barcode: QR code
Rotation: 0°、90°、180°、270°

④Physical Features:
Gross weight: 122.2893.9960.07mm(LWH)
Dimensions: 0.343 kg

⑤Software:
Systems: Windows/Android/iOS

⑥Power supply:
Battery: DC 7.2V / 2500 MAH
Charging input: Standard USB cable charging: 5V/2A
Optional DC adapter charging: 9V/2A

⑦Environmental conditions:
Work environment: 0 ~ 45℃， 10 ~ 80% RH no condensing
Storage environment: -10 ~ 60 ℃， ≤93% RH(40℃） no condensing

Receipt print mode:
Printing method: Direct thermal
Resolution: 203 DPI
Print width: Max. 48mm
Max. print speed: 90 mm/s

①Media:
Media type: Thermal paper
Media width: 58mm
Media external diameter: 50mm
Paper out method: Tearing-off

②Performance Features:
Print head detection: Thermistor
Print head position detection: Micro Switch
Media detection: Photoelectric Sensors
Interface: USB + Bluetooth
Storage: Flash 576 kb

③Fonts/Graphics/Symbologies:
Character size: Font A: 12X24, Font B: 9 X 17, CHN: 24*24
1D bar code: UPC-A/UPC-E/JAN13 (EAN13)/ JAN8((EAN8)/CODE39/ITF/CODABAR/ CODE93/CODE128

2D barcode: QR code
Rotation: 0°、90°、180°、270°

④Physical Features:
Gross weight: 122.2893.9960.07mm(LWH)
Dimensions: 0.343 kg

⑤Software:
Systems: Windows/Android/iOS

⑥Power supply:
Battery: DC 7.2V / 2500 MAH
Charging input: Standard USB cable charging: 5V/2A
Optional DC adapter charging: 9V/2A

⑦Environmental conditions:
Work environment: 0 ~ 45℃， 10 ~ 80% RH no condensing
Storage environment: -10 ~ 60 ℃， ≤93% RH(40℃） no condensing
